Ultra 7 SmallHD 7-inch touchscreen camera monitor with 2300nits brightness
- Ultra Bright (2300nits)
- Dust and water resistant with an IP53 rating
- 6G-SDI for modern 4K end-to-end workflows
- Camera Control compatible with all current SmallHD licenses
- Function Buttons for tactile control
Ultra 7
Ultra Smart. Ultra Bright. Ultra Durable.
Designed to withstand the extremes of any production environment, Ultra 7 has the processing power of our 4K Production monitors, customizable function buttons,
and shock absorbing bumpers.
Rugged, powerful, and feature-rich, the Ultra 7 offers 2300nits of brightness, 6G-SDI that allow you to ingest 4K signal, a 2-Pin power passthrough for cleaner
builds, an Ethernet port for camera control, plus a joystick and tactile physical buttons for control in any conditions. Utilize all your favorite PageOS tools, functions, and settings pages on a fully-loaded 7-inch touchscreen monitor.
2300nits Max Brightness 6G-SDI 4K End-to-End Workflows
1000:1 Contrast Ratio
Camera Control ARRI, RED®, Sony
1920×1200 Resolution 10-Bit Color Processing
Raised edges protect touchscreen from damage
Rubber shock- absorbing bumpers
Touchscreen 4X Custom-
Function Buttons Back-button Joystick
COMING SOON
Ultra 7 + Teradek Bolt 6
Built-in Wireless Video
Finally, an ultra bright 7-inch handheld monitor with a fully-
contained Teradek Bolt 6. Rugged and protected from the
elements, this is a handheld monitor that can withstand even the
most destructive directors.
Built-in Bolt 6 units utilize the clear airwaves of the newly-open
6GHz spectrum, with RX and TX models that are compatible with
any Teradek Bolt 6, and backwards-compatible with any Bolt 4K
system in 5GHz mode.
BACKWARDS COMPATIBLE
Works with Teradek
Bolt 4K and Bolt 6
LONG RANGE
750ft & 1500ft range
models available
SEAMLESS DESIGN
Ergonomic, Cable-Free
Workflow
QD-LED Edge-Lit LCD
Panel Technology
SmallHD LEDs for Ultra 7 panels have the highest tolerance for
color uniformity. These LEDs are built into an edge-lit panel stack
that diffuses and focuses the light through a quantum-dot film,
ensuring the purest color accuracy on our panels. The result is an
extremely bright monitor with excellent image fidelity.
Built to Withstand the Harshest
Production Environments
With an IP53 rating and ultra-durable water, dirt, heat, cold, and drop-
resistant chassis, Ultra 7 was designed to withstand all the rigors and
elements that professional filmmakers endure.
Fully Sealed
All electronic components are
sealed with caps to protect
against dust and water.
Impact Resistant
Able to withstand most drops,
tumbles, and impacts with
shock-absorbing bumpers.
Thermal Management
Ultra 7 can operate at freezing
as well as scorching
temperatures (0º-40ºC).
Strength & Durability
Strong, durable chassis
with raised edges to
protect the screen.
Water Resistant
Water resistant with protection
against damp scenarios.
SNAP OUT THE SUN
The Folding Magnetic Sunhood
The reimagined Ultra 7 sunhood connects to the monitor in
seconds using a powerful magnetic array. This means no
tools for installation or removal. When closed, the sunhood
also provides total protection of the panel.
Workflow, Premium UX
SEE WHAT’S NEW IN PAGEOS
Smarter, more intuitive software tools for at-a-glance
adjustments, effortless navigation, and more accurate
exposure and color control. Personalized Page Profile,
Focus and Exposure Assist, Lookaround Camera Control,
Tetrahedral LUT Interpolation, Advanced Teradek RT
Overlays, and more.
LOOK-AROUND CAMERA CONTROL
A Camera Interface on Every Page
View and adjust crucial camera-control functions and
PageOS tools at the same time on Smart 7 Series
Monitors with a camera-control interface anchored to
every page.
SKU 16-0727
Product ID 6876281045125
Environmental
Item Weight (oz) 32
Height (in) 1.36
Width (in) 5.12
Length/Depth (in) 8.23
Display Panel Type IPS LCD
Diagonal Size 7.02″
Max Brightness 2300nits
Contrast 1000:1
Gamut 95% DCI-P3 Coverage / 98% REC 709
Color Depth 10-bit Processing (8-bit panel)
Backlight Type LED Edgelit
EVF Resolution 1920×1200
Input Signal 3G-SDI Input Types YCC 4:2:2 @ 10-bits: 1080p60, 1080p59.94, 1080p50, 1080i120, 1080i119.88, 1080i102
6G-SDI Input Types YCC 4:2:2 @ 10 bits: DCI-4Kp30, DCI-4Kp29.97, DCI-4Kp25, DCI-4Kp24, DCI-4Kp23.98, 2160p30, 2160p29.97, 2160p24, 2160p23.98 YCC 4:4:4, YCC+A 4:4:4:4, RGB, RGB+A @ 10 bits: DCI-2Kp60, DCI-2Kp59.94, DCI-2Kp50, DCI-2Kp48, DCI-2Kp47.95, 1080p60, 1080p59.94, 1080p50, 1080p48, 1080p47.95 YCC 4:4:4, YCC+A 4:2:2:4, RGB @ 12 bits: DCI-2Kp60, DCI-2Kp59.94, DCI-2Kp50, DCI-2Kp48, DCI-2Kp47.95, 1080p60, 1080p59.94, 1080p50, 1080p48, 1080p47.95
HD-SDI Input Types YCC 4:2:2 @ 10-bits: 1080p30, 1080p29.97, 1080p25, 1080p24, 1080p23.98, 1080psf30, 1080psf29.97, 1080psf25, 1080psf24, 1080psf23.98, 1080i60, 1080i59.94, 1080i50, 720p60, 720p59.94, 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.100
SD-SDI Input Types YCC 4:2:2 @ 10-bits: 480i59.94, 576i52
HDMI Input Types YCC 4:2:2 @ 12 bits, 8/10/12/16 bit color in RGB & YCC 4:4:4: 3840×2160 30p, 1080p60, 1080p59.94, 1080p50, 1080p30, 1080p29.97 1080p25, 1080p24, 1080p23.98, 720p120, 720p119.88, 720p100, 720p60, 720p59.94 , 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.98, 480p240, 480p239.76, 480p120, 480p119.88, 480p60, 480p59.94, 576p200, 576p100, 576p50, 480i240, 480i239.76, 480i120, 480i119.88, 480i60, 480i59.94, 576i200, 576i100, 576i52
Output Signal 3G-SDI Output Types
YCC 4:2:2 @ 10-bits: 1080p60, 1080p59.94, 1080p50, 1080i120, 1080i119.88, 1080i102
HD-SDI Output Types YCC 4:2:2 @ 10-bits: 1080p30, 1080p29.97, 1080p25, 1080p24, 1080p23.98, 1080psf30, 1080psf29.97, 1080psf25, 1080psf24, 1080psf23.98, 1080i60, 1080i59.94, 1080i50, 720p60, 720p59.94, 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.100
SD-SDI Output Types YCC 4:2:2 @ 10-bits: 480i59.94, 576i52
HDMI Output Types YCC 4:2:2 @ 12 bits, 8 bit color in RGB & YCC 4:4:4: 2160p30, 2160p29.97, 2160p25, 2160p24, 2160p23.98, 1080p120, 1080p119.88, 1080p100, 1080i120, 1080i119.88, 1080i100, 1080i60, 1080i59.94, 1080i50, 720p240, 720p239.76, 720p200 YCC 4:2:2 @ 12 bits, 8/10/12/16 bit color in RGB & YCC 4:4:4: 1080p60, 1080p59.94, 1080p50, 1080p30, 1080p29.97 1080p25, 1080p24, 1080p23.98, 720p120, 720p119.88, 720p100, 720p60, 720p59.94 , 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.98, 480p240, 480p239.76, 480p120, 480p119.88, 480p60, 480p59.94, 576p200, 576p100, 576p50, 480i240, 480i239.76, 480i120, 480i119.88, 480i60, 480i59.94, 576i200, 576i100, 576i51
Audio Output Types HDMI & SDI – Incoming Audio Stream is sent downstream via HDMI or SDI connection
Data I/O SDI 1x BNC 6G input and 1x BNC 6G input/output (12G BNC compatible)
HDMI 1 input and 1 output: HDMI Type-A Receptacles (full size)
Audio 1x 3.5mm 3-pin Stereo Headphone Jack Ethernet RJ45
Power Connector 2-Pin Locking Connector Voltage
DC in – 10V minimum to 34V maximum, Battery terminals – 6.0V minimum to 16.8V max
Power Supply Recommend DC 12~15V at ~2.5 amp or greater
Battery Types V Mount, Gold Mount Micro Battery Plates
Overload Protection DC input: Reverse polarity
Software Pixel Zoom
1.1-2.0x & 2.0-8.0x via swipe up/down. Infinitely adjustable via pinch & zoom
Frame Guides Preset Aspect Ratios & Customizable
DSLR Scale Canon 5DMkii & Canon 7D Custom Scale
Yes (Underscan Only) Anamorphic De-Squeeze 0.75x, 1.33x, 1.5x, 1.66x, 2.0x, 2.5x
Image Rotate Automatic or Manual Control
Image Flip
Automatic or Manual Control
Cross Conversion
Yes: HDMI → SDI & SDI → HDMI
Focus Assist
User Adjustable Color Style and Intensity
Peaking
User Adjustable Intensity
False Color
Rainbow, Arri Style, Custom with up to 10 nodes
Zebra
Dual – User Configurable
Waveform
Luma & RGB Style, Fully User Customizable w/ Region of Interest Highlighting
Vectorscope
Yes
RGB Parade
Fully User Customizable
Histogram
Luma & RGB Style
Image Capture
Yes
LUTS
– 33pt User LUT instead of 17pt – 33pt Cal LUT instead of 17pt – LUT tool continues to work after removable media containing the LUT has been removed
Custom LUTS
– Loadable as Looks on Pages or as Systemwide Color Calibration via the settings menu – LUT Downstream: Available on SDI or HDMI Out. Applied on Output Preview Page – LUT Import: via SD Card or USB Storage Device
Color Pipe
– Unique Calibrations may be saved to each Color Pipe – Accurate color processing
Overlay
With Opacity Slider and Blink Setting
Audio Meters
HDMI & SDI up to 8 channel
Multi-View
2 camera feeds simultaneously while filling vertical 9×16 screen with two 16:9 images on its vertical axis (Coming Soon)
