TVLogic 7″ F-7H MK2 FHD HDR Field Monitor + แถมฟรี LCD Hood F-7H MK2 ครับ
- 7″, 1920 x 1080, 3G-SDI and HDMI Monitor
- Updated Image Processing Engine
- Sharper Image, Preset Touch Buttons
- 3600 cd/m² Maximum Brightness
F-7H mk2 : Ultra-Bright 7’’ Field Monitor with Enhanced Sharpness
The F-7H mk2 is a 7’’ 1920×1080 resolution field monitor that offers max. luminance of 3,600nits with enhanced sharpness and peaking boost function via new image processing engine. While delivering the same high quality picture and professional features of the previous model, F-7H mk2 shows far less reflection with Anti-Glare film and faster access to frequent preset modes via front touch keys.
Size | 7″ |
Resolution | 1920 X 1080 (16:9) |
Pixel Pitch | 0.078(H)x0.078(V)mm |
Color Depth | 16.7M |
Viewing Angle | 160°(H) / 160°(V) |
Luminance | 3,600cd/m2 |
Contrast Ratio | 1,200:1 |
Display Area | 151.2(H)×94.5(V) mm |
Input
1 X BNC | 3G-SDI A Channel Input |
1 X HDMI | HDMI Input |
Output
1 X BNC | 3G-SDI Output |
1 X HDMI | HDMI Output |
Audio
Audio In | Embedded Audio |
Audio Out | Analog Stereo (Phone Jack) |
FPGA Functions
, 3G-SDI Level A/B, Audio Level Meter Display, Blue Only, Focus Assist, H/V Delay, H/V Flip, Key Lock, Luma(Y’) Zone Check, Marker, Max Brightness On/Off, Mono, Range Error, Time Code Display, User Aspect, Various Scan Modes, Waveform/Vector, Zoom, Camera Lut., Arri Camera Metadata |
Closed Caption
Calibration
, 3D LUT & Adjustable Gamma, 3rd Party 3D LUT Import |
Other Functions
USB | Firmware update by USB cable | Firmware update by USB memory stick |
Ethernet | ||
Conversion | HDMI-to-HDMI, HDMI-to-SDI, SDI-to-HDMI, SDI-to-SDI, |
Options
Battery Bracket, HDMI Bracket, Camera Mount Ball Head, Carrying Case, D-Tap Cable, External Acrylic Filter, Gold Mount, Sun Hood, V-Mount |
